1. Features:
Galvanized steel, square-locked core
PVC vacuum jacketed
Light weight
Water resistance
Excellent flexibility
Temperature range from -20oC to +105oC
PVC colour black (standard), grey or orange (made to order)
Nickel plated brass fittings
Galvanized malleable iron fittings
Stainless steel fittings



Wire full protection galvanized steel tube

2. Applications:
General indutrial and commerical electrical wiring protection
Machining centres and robotics
any narrow space in static applications



  According to customer's samples and specifications, we can manufacture the VJ type flexible conduit to suit special applications, such as wider temperature range, flame

retardent, etc.



3 Specifications






Part No.

Normial Size

Inner Diameter

Outside Diameter

O.D After PVC Coated

Length Of Each Roll


mm

mm

Interlocked

Squarelocked

M


SS-10

3/8"

12.5

15.7

18.0

16.6

50


SS-11

1/2"

15.7

19.1

21.3

20.0

50


SS-12

3/4"

20.8

24.3

26.7

25.5

50


SS-13

1"

26.0

30.0

33.2

31.6

30


SS-14

1-1/4"

35.0

40.0

42.2

42.0

30


SS-15

1-1/2"

40.0

45.0

48.0

47.0

20


SS-16

2"

51.0

56.0

59.6

59.0

10
