Type: H05RR-F300/500V
EPR insulated and EPRsheathed flexible cords
Norm: DIN VDE 0282-4, BS6500, BS7919, NFC32-102-4, HD22.4S3
Construction:
Conductor: Tinned annealed copper conductor flexible class5 acc. To EN60228
Insulation: EPRrubber typeEI4
Sheath: Rubber compound type EM3
Colour of sheath: Black
Core identification: Acc. To HD308S2 and BS6500, BS7919
Twin core blue and brown
3-core green/yellow, blue and brown
4-core green/yellow, black, grey, brown
4-core* green/yellow, blue, black and brown
5-core green/yellow, blue, black, grey and brown
* for certain applications only.
Maximum conductor operating temperature: +60º C
Lowest ambient temperature for fixed installation (static): -30º C
Lowest installation temperature: -255º C
Maximum short-circuit conductor temperature: +200º C
Test voltage 50Hz: 2000v
Flame retardant: EN60332-1-21(IEC60332-1)
Minimum bending radius: 7, 5*D, D-overall diameter of cable
The product is conformed with the RoHS Direktive 2002/95/CE, low-voltage direktive 73/23/EEC and 93/68/ECC
Application: For general use in domestic premises, kitchens, offices, for supplying appliances where the cables are subjected to low mechanical stresses (eg, vacuum cleaners, cooking appliances, soldering irond, toasters).
