Brand:SUNLIKE/OEM
Model:SG12-200
MOQ:10 Pieces
Deep Cycle Solar Gel Battery 12V200Ah for Solar
Long Life Solar Gel Battery 12V200Ah
Model:SG12-200 Solar Gel Battery
Warranty: 3 years deep cycle battery.
Design Life: 15-20 years.
Certificates: CE, IEC, ISO9001, ISO14001
OEM/ODM Available.
Deep Cycle Solar GEL Battery
Key Specifications/Special Features:
1: Long service lifespan: 15 to 20 years design lifespan
2: Low self-discharge: Lower than 3% of rated capacity per month under normal operating temperature
3: ABS case (can be made with flame retardant V0)
4: No memory effect after repetitious usage or discharges
5: Maintenance-free operation
6: Sealed construction and leak proof
7: Safety valve regulated system and Non Spillable
8: Operating in any position
9: Deep discharge recovery
10: Wide operating temperature range -20degree to 60degree
Deep Cycle Solar Gel Battery 12v200ah with 3years Warranty
Applications:
1: Telephone switchboard, electric equipments, medical equipments, instruments, and meters
2: Computer, uninterrupted power source (UPS), Inverter
3: Power transmission and transformer station, switch control, and accident lighting
4: Fire fighting, safety device, and alarm monitoring
5: Aviation, spaceflight, and power storage
6: Automatic office system
7: Radio communication system
8: Emergency lighting and car/ship starting system
9: Portable electric appliances and mining system
10: Traffic and navigation signal lamp
11: Solar/Wind/Hybrid power system
OUR SOLAR GEL BATTERY MATERIAL ADVANTAGES:
1) Container/Cover: Made of UL94HB and UL 94-0ABS Plastic, fire resistance and water proof.
2) 99.99% pure new lead NEVER use recycle lead.
3) Negative Plates: Use the special PbCa alloy grids, optimize the recombination efficiency and less gassing.
4) High quality AGM separator
5) Positive plates: PbCa grids minimize corrosion and prolong life.
6) Terminal post: Copper or lead material with maximum conductivity, enhance the high current rapidly.
7) Vent Valve: Allows the release of the excess gas automatically for safety.
8) Three steps of Seal procedures: Ensure battery completely sealed with safety, never leakage and volatile acid, longer life.
about SUNLIKE:
We SUNLIKE Energy Technology Co.,Limited manufacturer solar batteries, AGM Sealed Lead Acid Batteries and Solar Gel Batteries 2V/6V/12V since 2001, mainly used for solar power, wind power, ups system, inverter system, telecom, golf cart, electric vehicles and so on.
Web:www.sunlikebattery.com.
Tel: +86-15818568975.
linkedin:https://cn.linkedin.com/in/upsbattery.
Facebook:http://www.facebook.com/leadacidbatteries.
Pinterest:https://www.pinterest.com/solarbattery/.
| Model | Voltage(V) | Capacity(ah) | Dimension(mm) | Weight(kg) | ||
| SG12-38 | 12 | 38 | 195*165*175*180 | 12.8 | ||
| SG12-55 | 12 | 55 | 230*138*201*212 | 15.5 | ||
| SG12-65 | 12 | 65 | 350*167*176*176 | 20 | ||
| SG12-85 | 12 | 85 | 260*169*211*231 | 23.3 | ||
| SG12-100 | 12 | 100 | 329*173*210*230 | 28.5 | ||
| SG12-120 | 12 | 120 | 405*173*210*230 | 33.5 | ||
| SG12-150 | 12 | 150 | 484*171*239*241 | 42.5 | ||
| SG12-180 | 12 | 180 | 532*206*216*221 | 53 | ||
| SG12-200 | 12 | 200 | 522*240*218*242 | 56 | ||
| SG12-250 | 12 | 250 | 522*240*218*242 | 62 | ||
| SG12-300 | 12 | 300 | 522*269*218*242 | 69 | ||
www.sunlikebattery.com
Notice:
Don't near the hot source and don't under the sunshine.
Don't charge in the sealed container.
No short circuit. It should be addition charge if you don't use, and single charge per three months, to avoid irreversible sulfating. The battery should be changed when the battery jar broken or the electrolyte omitted, to avoid acid corrosion.
Don't store in the space of acid gas.
You should be careful and regular check when use the battery. To avoid the battery don't work. You should change the battery if the capacity is not full or has been damage, especially after one year using.
Don't put the battery in the fire, or it will explode.
Please use cotton cloth to clean, if the battery is broken down and leak electrolyte. Please wash your skin when touch the electrolyte.
Don't clean the battery by using the organic solution. (e. G. Petrol)
