Brand:east
Model:WAW-1000B
MOQ:1 Sets
Applications:
The machine can be used for tensile, compression, bend, shear, peeling, tearing, circulation, and creep test of metal, non-metal material and components. It is in keeping with the international standards of metal’s tensile and compression test in room temperature.
Main specifications:
| WEW-1000B(6 columns) | |
| Max.Load kN | 1000 |
| Max.distance of tensile test mm | 700 |
| Max.distance of compressive test mm | 660 |
| Thickness of flat test bar mm | 0-40 |
| Diameter of round test bar mm | 20-60 |
| Stroke of piston mm | 250 |
| Size of hold-down plates mm | 235×235 |
| Distance between support rollers for bend test mm | 60~700 |
| Distance between two columns in tensile or compressive test mm | 650 |
| Max.speed of plate mm/min | ≥100 |
| Max.ascending and descending speed of crossbeam mm/min | ≥300 |
| Power input kW | ≈2.5 |
| Dimension of main body (L×W×H)mm | 1010 ×700×2415 |
| Dimension of Control desk (L×W×H))mm | 1130×700 ×940 |
| Weight kg | ≈3500 |
| Noise dB | ≤75 |
