Brand:UPSEN
Model:Ideal Star Series 300W-1000W
MOQ:5 Pieces
CE approved single phase 12/24/48V inverter for Computer room
Pure Sine Wave Inverter Ideal Star Series 300W-1000W (1ph in/1ph out)
Key Features:
1:Built-in high speed cooling fan
2:High Quality and High Performance
3:High-precision voltage stability technology
4:Input and output are completely independent
5:Pure sine wave output, available for sensitive load
6:Excellent double-faced circuit board and components
7:Microprocessor control guarantees high reliability
8:Low noise design, strong anti-interference, low radiation
9:Intelligent temperature control cooling fan, effectly prevent inverter over-temperature inside
10:Pure sine wave combined inverter, automatic charger and commercial power battery automatic switch
11:CPU controled intelligent cooling fan, greatly extend life time of the fan, more efficiency and save energy
Application
Home,office,Automation systems,Computer room,Computers,
Data center,control room,Portable power supply,Street Lighting,Precision instrument,Commercial facility,Intelligent equipment, etc.
Technical Specification
| Model | IS300 | IS500 | IS600 | IS800 | IS1000 | |
| Rated power | 300W | 500W | 600W | 800W | 1000W | |
| Peak power | 600W | 1000W | 1200W | 1600W | 2000W | |
| Start method | Soft start | |||||
| DC input | Rated input voltage | 12V/24V/48V(optional) | ||||
| AC Output | Voltage | 100V/110V/220V/230V/240V(optional) | ||||
| Frequency | 50HZ/60HZ(optional) | |||||
| Waveform | Pure Sine Wave | |||||
| Maximum DC | 110% | |||||
| loads output power | ||||||
| Total Harmonic Distortion | THD≤2% | |||||
| Rated output efficiency | >85% | |||||
| Protection | High input voltage shutdown | 15.0V, automatically shutdown, alarm twice | ||||
| Low input voltage shutdown | 10.0V, automatically shutdown, alarm twice | |||||
| Low input voltage alarm | 10.5V, no power off, alarm once | |||||
| Over temperature protection | When the temperature of internal heat sink is above 80ºC, it will shutdown automatically and alarm three times | |||||
| Short circuit protection | Shutdown, alarm five times, restart automatically | |||||
| Overload | Shutdown, alarm four times, restart automatically | |||||
| protection | ||||||
| Reverse Input | Quick-break fuse | |||||
| Environment | Temperature | -10 - 40ºC | ||||
| Humidity | 0%-95% | |||||
| Noise of the fan | <55dB | |||||
| Insulation resistance | EN50081-1/EN55022 | |||||
| Insulating strength | EN50081-1/EN55022 | |||||
| Weight (Kg) | 1.16 | 1.92 | 3 | |||
| Size | 235*115*65 | 295*132*72 | 320*185*72 | |||
| W*D*H(mm) | ||||||
| *Specifications are subject to change without prior notice. | ||||||
