1. Model:

AD116-22B Indicator light (pilot light)

AD116-22BFS- Flashing indicator light

AD116-22B/K – LVP indicator light

AD116-22B/F – Dischargeable light

2. Features:

    ●LED round flush lens.

●High brightness LED lighting

●Fast and easy to install

●Mounting size:Φ22/25mm common use

●Protection degree of the top part: IP65. IP67 is available on request.

●Color: R-red, Y-yellow, B-blue, G-green, W-white

●Rated Voltage：6V, 12V, 24V, 110V – AC/DC

              220V, 380V, 440V AC

Remark： GQ/AD22-22B – Common brightness Model

3. Application

    This series indicator light ( pilot light) are used as indicating, accidental signals and other pilot signal of instrument circuit in the areas of electric power, telecommunication, machinery, marine, textile, printing, mining etc

4. Technical Parameters

Life of continuous working ≥ 30000h

Allowable instantaneous voltage fluctuation: ±20%

Comparative tracking index (CTI)≥100，flame retardant

Power frequency withstand voltage：2.5kV

Insulation resistance：≥value="50" tcsc="0" unitname="m" w:st="on">50MΩ
