Lovol Natural Gas Generator Model YDNL-30 YDNL-50 YDNL-80 Rated Frequency 50/60HZ Power Factor 0.8 Rated Voltage 400/230V Rated Power (KW/KVA) 30/37.5 50/62.5 80/100 Standby Power (KVA) 33/41 55/68 88/110 Rated Current (A) 54 90 144 Phase/Wire 3Phase,Website:http://www.yidanenggenerator.com, 4Wire Alternator Brand Stamford Control System Smartgen, Deepsea, ComAp Overall Size (mm) 1800*720*1200 2000*750*1200 2000*750*1400 Weight (kg) 780 1150 1300 Lovol Gas Engine Model 1004NG 1006NG 1006TANG Rated Power (kw) 35 56 90 No. of Cylinder 4. L 6.L 6.L Speed(RPM) 1500/1800 Bore×Stroke (mm) 100*127 Displace(L) 3.99 5.99 5.99 Gas Consumption (m3/kw.h) 0.33 Oil Consumption (g/kw.h) 2 Cooling Type Closed water cooling Speed Governing Mode ESC Starting Mode Electric ●Founded in 1998, the company now has total assets of 16.1 billion Yuan and 16,000 employees. ●Lovol is the largest agricultural equipment manufacturer in China ●Yidaneng is the Exclusive Agent of Lovol Gas Engines ●In 2014, the sales revenue has reached 21.98 billion RMB. ●The brand value of Lovol is evaluated as 35.553 billion RMB by the World Brand Lab. Pressure Regulator: To regulate the pressure of the gas supplier and make sure stable gas pressure. Pressure Meter: To show and monitor the gas pressure within the normal range Anti-explosion Valve: To release the pressure in case the mixed gas is ignited in the intake manifold. In this way, the generator will be well protected from ignition resulted from mistaken adjustment of advance angle of ignition Flame arrester: This part is designed to prevent the fire entering the gas tank from the engine. As natural gas and biogas are highly flammable gas, the back-fire is highly dangerous to the gas source. So it is very important to have this flame arrester. 30-50KW silent Lovol natural gas generator 30-50KW silent Lovol natural gas generator working for natural oil field of Sinopec in northwest China.
