| ELECTRICAL DATA | |
| Temperature Range | -40~+90 |
| Characteristic impedancd | 50Ω |
| Frequency range | 0~6GHz |
| Working voltage | 170V(r ms) |
| VSWR | ≤1.25 |
| Insulation Resistance | ≥1000MΩ |
| Dielectric Withstanding voltage | 500V(r ms) |
| Contact resistance | Center conductor ≤10mΩ |
| Outer conductor ≤5mΩ | |
| Durability | 500 Cycles |
| Material And Plating | |
| Body | Brass , gold plated |
| Male center contacts | Phosphor bronze , gold plated |
| Female center contacts | Beryllium copper , gold plated |
| Insulators | PTFE |
| Crimp Ferrules | Copper alloy , nickel or gold plated |
