Brand:-
Model:-
MOQ:500 Pieces
Send Inquiry
ELECTRICAL DATA Impedance 50Ω Frequency range (for connector interface) DC～18GHz Dielectric withstanding voltage (at sea level) ≥750-1500V,50Hz (depending on cable) Working voltage (at sea level) ≥250-500V,50Hz (sea level) / ≥65-125V,50Hz (Height 21000M) Insulation resistance ≥ 5000 mΩ Contact resistance Inner conductor: ≤3mΩ Outer conductor: ≤2.5mΩ RF leakage(2-3GHZ) Flexible: ≥60dB Semi-rigid cable: ≥100dB MECHANICAL DATA Coupling nut torque 0.8Nm--1.1Nm / 7.1 in.lbs--9.7 in.lbs Coupling nut retention force ≥270N / 60.7 lbs Contact captivation axial ≥27N / 6.1 lbs Durability (matings) ≤500 ENVIRonMENTAL DATA Temperature range -65°C to +165°C MATERIAL DATA Bodies, outer contacts Beryllium copper--Au plating Stainless steel--Passivation Brass--Au plated / ternary alloy plating Phosphor bronze --Au plating Pin contacts Brass/Beryllium copper--Au plating Socket contacts Beryllium copper / Phosphor bronze--Au plating Crimp ferrules Brass--Au plating Insulator PTFE
