Brand:sunrise
Model:42BLYS
MOQ:-0 -
Our superb technique and excellent credit will enable us as a producer to stand up to the harsh business environment and bring us forwards. BLDC Servo Motor 42BLYS is mainly applied in the industry equipmwnt, ticket machine, printer, medical machine.
Specifications of Series 42BLYS
|
|
|
| 42BLYS3A42 | 42BLYS3A42 | 42BLYS3A42 |
| Specification |
| Unit |
| ||
| Rated voltage | U | V | +24 | ||
| Rated out power | P out | W | 11 | 22 | 33 |
| Rated speed | n N | rpm | 3000 | ||
| Rated current | I N | A | 0.9 | 2.1 | 3.0 |
| Rated torque | T N | N.m | 0.04 | 0.07 | 0.10 |
| Peak current | I P | A | 2.7 | 6.3 | 9 |
| Peak torque | T p | N.m | 0.11 | 0.21 | 0.3 |
| Voltage constant | K E | V/Kmm | 3.37 | 3.37 | 3.37 |
| Torque constant | K T | N.m/A | 0.035 | 0.035 | 0.035 |
| Rotor inertia | J | Kg.cm 2 | 0.25 | 0.35 | 0.45 |
| Number of poles | N P |
| 4 | ||
| Encoder |
| CPR | 500 | ||
| Winding class |
|
| B | ||
| Motor weight |
| Kg | 0.35 | 0.5 | 0.8 |
