Mifare DesFire EV1 Smart Contacless 13.56MHz RFID Proximity Card based On NXP MF3 IC D41

DAILY RFID Mifare DesFire EV1 contactless smart card is based on NXP MF3 IC D41, which is connected to a coil with a few turns and then embedded into a standard ISO smart card. The transport protocol complies with part ISO 14443-4. DesFire supports ISO7816-4 compliant APDU message structure as well. It is contactless transmission of data and energy, no battery is needed.

Mifare DesFire EV1 is an upgrade to DesFire, has higher level of security. Mifare DesFire EV1 achieves using a 3DES hardware cryptographic engine for enciphering transmission data. card can hold up to 28 different applications and 32 files per application. The size of each file is defined at the moment of its creation, making Mifare Desfire EV1 a truly flexible and convenient product.

Cardholders can experience convenient contactless ticketing while also having the possibility to use the same device for related applications such as payment at vending machines, access control or event ticketing.

Applications:

Access control, People Identification, Payment System, secure applications, such as transport ticketing, time attendance solutions, car parking, road tolling, time attendance solutions, car parking, road tolling

Specifications:

1.      Type: Contactless R/W

2.      Operating Frequency: HF (13.56MHz)

3.      Protocol: ISO14443 Type A

4.      IC Data Sheets as PDF Download

Mifare DesFire EV1 (13.56 MHz, 4K Byte, R/W, ISO 14443 A) –

http://www.smart-rfid-tag.com/Mifare_DesFire_EV1_Data_Sheet.pdf

5.      Size: 85.6×54×0.86mm

6.      Reading Distance: 5~8cm

7.      Material: PVC

8.      Operating Temperature: -25º C to +50º C

9.      Storage Temperature: -40º C to +60º C

Printing:

l  Offset Printing

l  Silk Screen Printing

l  Single Card Printing (M.C.O.P)

l  Thermal Printing

Option:

Competitive Advantage:

&
