Brand:Grewin
Model:GWCTC
MOQ:50 Pieces
Clamp on current transformer input 100a output 0.333v 1.5v clamp on sensor
The GREWIN CTC series of clamp on current transformer are designed for fast and easy installation.The clamp on core design permits non-contactcurrent measurements through magnetic field induction without disconnecting cables or busbar circuits for CT installation. This method permits a safer, easier and portable current measurement.
The following is our detailed information of clamp on current transformer input 100a output 0.333v 1.5v clamp on sensor
| Clamp on current transformer(applications) |
| Silicon Steel cores provide moderate accuracy and lower cost for appropriate current |
| |
| Clamp on current transformer (features) |
| Low cost |
| 6standard sizes |
| Clamp-on core design,safer,easier installation, portable |
| Both Silicon Steel & Nickel Alloy cores available |
| Clamp on current transformer (specifications) | |
| Rated Primary current | 1A-200A |
| Output signal | mA/A or mV/A |
| Maximum Non-Destructive Current | 200A |
| Basic Accuracy | 1% |
| Safety | CAT III 600V |
| Dielectric Resistance | 1000MOhms @ 500 Vdc |
| Case Material | Polypropylene resinUL flame retardant rating 94-V0 |
| Voltage rank | 600Vac(isolated condition), 30Vac(bareness condition) |
| Maximum voltage | 600Vac |
| Useable frequency | 10Hz/60Hz |
| Maximum Cable Diameter | 2.05 inches (52 mm) |
| Dimensions | 4.37x8.5 x1.77 in. (111x216x45 mm) |
| Operating Temperature | -25℃ to +70℃ |
| Standard | IEC 60044-1 |
| Accessories | Supplied with feet for base mounting if required |
| Certification | RoHS compliant CE&ETL approved |
The following is the designing model of clamp on current transformer input 100a output 0.333v 1.5v clamp on sensor
