Brand:Grewin
Model:GWTA
MOQ:50 Pieces
The GREWIN TA series of Water proof three phase instrument current transformer 2A/0.1-0.3V is applicated in current monitor of AC motor, illumination device, air compressor and HVAC etc. Electrical energy manage, building control system.Current measurement, monitoring and protection for circuitry and equipment.
The following is our detailed information of our 1:2000 1:3000 0.2s 0.5s three phase ct three phase current transformer input 25a 50a 100a 150a ouput 0.1v 0.353v for AC motor
| Three Phase Instrument Current Transformer(specifications) | |
| Exterior Material | PBT Resin UL flame retardant rating 94-V0 |
| Interior Insulation | Epoxy Encapsulated |
| Isolation Voltage | 2500 Vrms for 1 minute |
| Dielectric Resistance | 1000 M Ohms @ 500 Vdc |
| Surge Withstand | 5000V(1.2/50μs standard shock wave)optional |
| Rated Load Resistance | 100K Ohms |
| Operating Temperature | -25 to +55℃,-40 to +85℃optional |
| Operating Voltage | 600Vac ,BIL 10KV Full Wave |
| Frequency | 50 to 400 Hz |
| Accuracy Class | defined in IEC 60044-1 Part 1 Voltage Transformers Class 0.1 0.2 |
| Certification | RoHS Compliant CE Approved |
| Three Phase Instrument Current Transformer(features) |
| Low cost |
| More than 10 standard size |
| Chassis mounting pattern Electromagnetic,need no power supply |
| Three Phase Instrument Current Transformer(applications) |
| Applications for current monitor of AC motor, illumination device, air compressor and HVAC etc. |
| Electrical energy manage, building control system. Current measurement, monitoring and protection for circuitry and equipment. |
The following is the parameter of different model of 1:2000 1:3000 0.2s 0.5s three phase ct three phase current transformer input 25a 50a 100a 150a ouput 0.1v 0.353v for AC motor
The following is the designing model of 1:2000 1:3000 0.2s 0.5s three phase ct three phase current transformer input 25a 50a 100a 150a ouput 0.1v 0.353v for AC motor
4.The following is the parameter of different model of 1:2000 1:3000 0.2s 0.5s three phase ct three phase current transformer input 25a 50a 100a 150a ouput 0.1v 0.353v for AC motor
