Brand:Grewin
Model:GWTA
MOQ:50 Pieces
The following is our detailed information of our instrument current transformer/single phase current transformer input 200-4000A for power measurement
| Single Phase Instrument Current Transformer(specifications) | |
| Exterior Material | PBT Resin UL flame retardant rating 94-V0 |
| Interior Insulation | Epoxy Encapsulated |
| Isolation Voltage | 2500 Vrms for 1 minute |
| Dielectric Resistance | 1000 M Ohms @ 500 Vdc |
| Surge Withstand | 5000V(1.2/50μs standard shock wave)optional |
| Rated Load Resistance | 100K Ohms |
| Operating Temperature | -25 to +55℃,-40 to +85℃optional |
| Operating Voltage | 600Vac |
| Frequency | 50 to 400 Hz |
| Accuracy Class | defined in IEC 60044-1 Part 1 Voltage Transformers Class 0.1 0.2 |
| Certification | RoHS Compliant CE Approved |
| Single Phase Instrument Current Transformer(features) |
| Low cost |
| More than 30 outline sizes |
| 5.0,1.0Aac secondary ratios available |
| Single Phase Instrument Current Transformer(applications) |
| For applications that require exceptional accuracy with minimal phase angle error |
| Applications would include Current,Power,Energy monitoring devices Relay protection device |
The following is the parameter of different model of instrument current transformer/single phase current transformer input 200-4000A for power measurement
