OUTLINE DIMENSIION (UNIT)mmElectrical dataRated Voltage240VAC/240VDCRated Current2A/环Dielectric Strength500VAC@50Hz,Website:http://www.slipringchina.com,60sInsulation Resistance1000MΩ/500VDCElectrical Noise＜0.01ΩLead SizeAWG26,color coded,FEP insulated,silver plated copperMechanical dataOperating Speed0-300rpmTemperature Range-40℃ - 80℃Operating Humidity≤75%Contact MaterialPrecious metalsframe MaterialEngineering plastics/Aluminum alloyTechnology indexParameterValueChannel count1Wavelength Range650-1650 nmInsertion loss＜2dB/RPT;＜3dB/RFC＆RSTInsertion loss ripple＜ /-0.25dB(Typical: /-0.15dB)Return Loss＞40dB(RPT);＞30dB(RFC＆RST);＞50dB(RPTA)Maximum speed2000 rpmPressure compensation1000psi(RPT) RPC Can withstand greater pressurePulling strength10NOptical power handling23 dBmWorkiong temperature-40～ 85°CStorang temperature-50～ 85°CPackage styleBoth ends of the fiber optic cable or FC/STHousing materialStainless steelFiber typesSM/MM,3mmOut coat or 2.9mm metal protective coverConnector typesFC,SC,ST,SMA or LC(PC/APC)Outside Dimensions17mm dia.body×26mm dia.(flaege)Weight50gVibration standardMIL-STD-167-1AMechanical shockMIL-STD-810GIP gradeIP 65(IP 68 optional)Options● Single and multiple rings design● Connector type● Single-mode or multimode● The sheath structure of optical fiber and its length
