Brand:ZG
Model:-
MOQ:20 Pieces
Send Inquiry
Feature
latching or non-latching
unmatched low cost
low insertion loss
high channel isolation
highly stability and reliability
epoxy-free optical path
Application
instrumentation
configurable optical ADD/DROP
optical signal routing
optical network protection/restoratioin
transmitter and receiver protection
network test system
Performance Specifications
| Parameters | Specification | Unit | |
| operating wavelength | 850,1310, or 1550±40 | 850/1300,850/1550,1310/1550 | (nm) |
| insertion loss | ≤1.0 | ≤1.2 | (dB) |
| Wavelength Dependant Loss | ≤0.25 | ≤0.30 | (dB) |
| Polarization Dependant Loss | ≤0.05 | (dB) | |
| Cross Talk | ≥35 | (dB) | |
| Return Loss | ≥35 | (dB) | |
| Switching Speed(typ.) | ≤10(typ.4) | (ms) | |
| Operating Voltage | 5 | (V) | |
| Power Handling | 500 | (mW) | |
| Durability | 10million | (cycle) | |
| Fiber Type | 65.2/125,50/125,105/125 | ||
| Operating Temperature | 0 ~ +70 | (ºC) | |
| Storage Temperature | -40 ~ +85 | (ºC) | |
| Dimension(LxWxH) | 27.2x12.8x7.5 | (mm) | |
