Features:
low cost
high channel isolation
low loss
high reliability and stability
light path without glue, lead
Applications:
the light signal top/bottom road;
system monitoring;
instrument equipment;
light signal routing
Performance index and specification:
| parameters | performance | unit | |
| operating wavelength | 850,1310 or 1510±40 | 850/1310,850/1550,1310/1550 | (nm) |
| insertion loss | <0.8 | <10 | (dB) |
| wavelength dependant loss | ≤0.25 | ≤0.30 | (dB) |
| polarization dependant loss | ≤0.05 | (dB) | |
| cross talk | >35 | (dB) | |
| return loss | >30 | (dB) | |
| switching time(Typ.) | <10(Typ.4) | (ms) | |
| operating voltage | 5 | (v) | |
| maximum power load | 500 | (mW) | |
| durability | 10 million | (cycle) | |
| operating temperature | 0 ~ +70 | (ºC) | |
| storage temperature | -40 ~ +85 | (ºC) | |
| fiber type | 50/125 or 62.5/125multimode | ||
| fiber length | 1.0+/ -0.1 | (m) | |
| dimension(LxWxH) | 27.2x12.8x7.5 | (mm) | |
