Brand:ZG
Model:-
MOQ:20 Pieces
Send Inquiry
Features:
unmatched low cost
low insertion loss
high channel isolation;
highly stable and reliable
epoxy-free optical path
Applications:
the light signal top/battom road
system monitoring
instrument equipment
light signal routing
Performance index and specification:
| parameters | specifications | unit |
| operating wavelength | 1260-1650 | (nm) |
| testing wavelength | 1310/1550 | (nm) |
| insertion loss | <0.7 | (dB) |
| polarization dependant loss | ≤0.05 | (dB) |
| wavelength dependant loss | ≤0.25 | (dB) |
| temperature dependant loss | <0.15 | (dB) |
| cross talk | 55 | (dB) |
| repeatability | <±0.05 | (dB) |
| return loss | >55 | (dB) |
| switching time | <10(Typ.4) | (dB) |
| coil resistance(Lead Angle 1-5 or 6-10) | 178±10% | (ohms) |
| operating voltage | 5 | (v) |
| maximum power load | 500 | (mW) |
| durability | >10million | (cycle) |
| operating temperature | 0~ +70 | (ºC) |
| storage temperature | -45 ~+85 | (ºC) |
| fiber type | SMF-28 | |
| fiber length | 1.0+/-0.1 | (m) |
| dimension(LxWxH) | 27.2x12.8x7.5 | (mm) |
