Product DetailBasic InfoModel NO.:XK-550BWarranty:1 YearProduct DescriptionFeatures1. It is mainly consist of rolls, frame, bearing, roll nip adjusting, screws, heating and cooling device, emergency stop, lubrication system and such sections as electrical controls and so on. 2. The rolls are made of alloy chilled cast iron. Their working surfaces are of high hardness and wear-resistant. 3. The working temperature of the bored roll is adjusted by steam, cooling water or oil in order to meet the requirements of milling process. 4. Roll nip adjustment is realized by hand or electrical operation which can obtain high accuracy and sensitivity. Technical SpecificationTypeRoller dia*length(mm)Front roller linear velocity(m/min)Velocity ratio of rollerFeeding quantity each time(kg)Max. diatance regulation(mm)Motor power(kw)Overall dimension(L*W*H)(mm)Weight (t) X(S)K-110110*3000-8adjustable1331600*1600*12001.5X(S)K-160160*3208.891:1.351-245.51160*920*13701X(S)K-230230*63512.711:1.195~108153100*1300*11002X(S)K-250250*63514.011:1.1710-158153200*1350*11002X(S)K-300300*70015.341:1.1712-2010223600*1400*13004X(S)K-360360*90016.451:1.2515-2510304100*1650*14506X(S)K-400400*101018.831:1.2725-3510404600*1850*14508X(S)K-450450*120024.121:1.2730-5010555100*2100*150012X(S)K-550550*153031.331:1.2050-60151106500*2200*175020X(S)K-610610*183030.101:1.1875( Thermal refining ) 151607200*2400*190035X(S)K-660660*213032.451:1.09165( Thermal refining )151807450*3660*208045X(S)K-660660*213018.601:1.24165( Thermal refining )152457465*3660*208045.6
