Applications : Shower Curtain WeldingLong length PVC linear welding (max to about 2 meter ) Machine overview and features : DXYL high frequency welding machine specially designed for bath curtain welding . If material is PVC ,Website:http://www.rf-welder.com, the hole and linear welding can be done in 1 time . TPU material also available to welded by this machine. The machine equipped with material shelf which used to put roll PVC or TPU material , add a heater in the upper electrode makes the TPU material easier to weld and also lower the power consumption.Shower curtain magnet machine and hole punching machine can also provided to assemble a production line DAVISON also have own tooling department which can design and make any electrode and die required for any demanding production needs.Technical DataModel DXYL25-1Power supply 3 phase 380 or 220VOutput power 25,000 WaltDia. of Cylinder 160mmDistance of Cylinder 100mmUpper electrode 300 x 2,000mmLower electrode 350 x 2,000mmMain Body Length: 2,500mm Width: 700mm Height: 2,000mmElectrical Box Length: 1,500mm Width: 1,100mm Height: 1,900mmMaterial Shelf Length: 2,500mm Width: 1,280mm Height: 1,260mm
