two models:

- FD8-10KW ( Pitch fixed)

- BFD8 -10KW ( Variable pitch )

10kw wind turbine off-grid working system normal data:

Model Name: FD8-10kw

Rotor diameter: 8m

Rated wind speed: 12m/s

Start up wind speed: 3m/s

Rated output power: 10kw

Max output power: 17kw

Working wind speed: 3m/s-30m/s

Survival wind speed: 45m/s

Generator type: PMG, 3 Phase AC generator

 Speed regulation method: Electromagnetic brake +Yaw

 Stop method : electromagnetic brake + manual brak

Working voltage: DC48-360V

 Rated rotate speed: 200rpm

Tower type: free stand tower

Tower height: 10m (can be special ordered)
