Brand:dragon
Model:TL-20KW
MOQ:-0 -
Send Inquiry
| TL-20KW's parameters | |||
| rotor diameter（m） | 10 | speed adjustment way | electromagnetism plus drift |
| blade material | intensive fiberglass | stop way | electromagnetism plus manual operation |
| blade quantity | 3 | generator type | permanent magnetism of three-phase current |
| rated speed(m/s) | 12 | rated power | 20KW |
| start up wind speed(m/s) | 4 | max power | 30KW |
| work speed(m/s) | 4-35 | rated rotor speed(r/min） | 200 |
| security wind speed(m/s) | 45 | work voltage | DC360V-500V |
| start up force moment(n/m) | 17 | weight of main body（kg) | 1400 |
