52.6M3 Water Capacity LNG Tank Container Trailer

Product type: HGJ9408GDY-2

Tank insulation method: High vacuum multilayer insulation

Work pressure(internal tank): 0.7MPa

Design temperature(internal tank): -196 degree centigrade

Equipment weight: 17800Kg

Rated load weight: 22200Kg

Full load weight: 40000Kg

Geometry water capacity of internal tank: 52.6m3

Full trust load distribution: towing pin: 16001Kg

                                                rear axle: 23999Kg

Trust load of support leg(full load): 22423Kg

Front turning radius: 1970mm

Clearance radius: 2275mm

Semi-trailer dimension(L*W*H): 13000*2500*3990mm

Distance between axles: 7070+1310+1310mm

Note; The height of coupling face of the no-load tractor is less than 1380mm. The single tyre or double tyres for the cryogenic semi-trailer depends on the customer requirements.

Product Features:

World class range of technical solutions and services

§  Design and Engineering Consultancy for Cryogenic Installations and Turnkey solutions

§  Establishment of single, multiple, specialty, calibration gases manufacturing facility.  This includes laboratory establishment as well as training to the operators at one of the Group Companies having ISO 9001, 14001 and 18001 accreditation.

§  Design and implementation of Purging solutions for various applications like equipment purging, blanketing, cross country pipeline purging, back up blanketing systems
