Floor heating intelligent control equipment include room temperature controller, valve controller and electric valve. Electric valve is installed in each loop pipe to control the recycled water of the loop pipe that the users can control the room temperature. At the same time, room temperature controllers are installed to measure indoor temperature and set temperature. The room temperature controller transmites the two temperature values to the valve controller. Then, valve controller controls the electric heating valve switch on the basis of the results of the set temperature and indoor temperature.

Technical Parameters

Power supply: AC24V

Product standard: One for two, One for three

Protection level: IP54

Ambient humidity: 95% no condensation

Ambient temperature: -10℃～60℃

Product size: 90mm×70mm×22mm
