Brand:ZHONGTIAN
Model:ZTSJG
MOQ:1 Sets
ZTSJG stationary scissor lift is the special hydraulic lift used for conveying cargos between building layers. The product is mainly used for conveying cargos up and down between workshops, warehouse and various working layers: lifting auto-mobiles between layers in stereo garage and understand garage. Product’ hydraulic system has anti-falling and over-loading safety productive devices, and all layers and lift working face can set operating buttons to realize multi-point control.
Technical parameters:
| Model | Lifting height (m) | Lowered height (mm) | Load capacity (kg) | Table size (m) | power (kw) | Rising time (s) |
| SJG 0.5-4.5 | 4.5 | 750 | 500 | 2*1 | 2.2 | 77 |
| SJG 1.0-4.5 | 4.5 | 850 | 1000 | 2*1.5 | 3.0 | 80 |
| SJG 2.0-4.5 | 4.5 | 900 | 2000 | 2.2*1.5 | 2.2 | 90 |
| SJG 1.0-7.5 | 7.5 | 990 | 1000 | 2.2*1.8 | 3.0 | 100 |
| SJG 2.0-7.5 | 7.5 | 1065 | 2000 | 2.4*2.4 | 4.0 | 105 |
| SJG 2.0-1.8 | 1.8 | 700 | 2000 | 2.5*2 | 3.0 | 50 |
| SJG 5.0-1.8 | 1.8 | 960 | 5000 | 3.5*2.5 | 4.0 | 88 |
| Lift height & Bearing capacity & Table size all can be customized. | ||||||
Application:
It is used to lift up and down large cargo to different levels, normally in the assembly line and other cargo transferring.
Model:
Single scissor lift platform;Dual furcation lift platform;Multi-furcation lift platform;
