Brand:cheuklift
Model:GTZ0
MOQ:1 Sets
Send Inquiry
| Model | Unit | GTZ0.16-8 | |
| Max platform height | mm | 8000 | |
| Max machine height | mm | 9100 | |
| Min platform height | mm | 985 | |
| Ground clearance | mm | 180 | |
| Platform capacity | kg | 160 | |
| Platform dimensions | mm | 730×730 | |
| Outrigger opening size | mm | 3830×2230 | |
| Lifting speed | m/s | 0.07-0.10 | |
| Working pressure | Mpa | 10 | |
| Ability | Grade | ≤5 | |
| Platform rolling speed | round/min | 1 | |
| Power | AC | V | 220-240 |
| DC | V | 24 | |
| Maintenance free battery | v/Ah | 2×12/200 | |
| Charger | v/A | 24/15 | |
| Lifting motor | AC | v/kw | 220/0.75-1.5 |
| DC | v/kw | 24/2.0 | |
| AC | AC | v/kw | 220/0.75-1.5 |
| DC | DC | v/kw | 24/0.75 |
| Overall length (L) | mm | 3600 | |
| Overall width (W) | mm | 1700 | |
| Overall height (H) | mm | 2220 | |
| NW | AC | kg | 1800 |
| DC | kg | 1960 |
