Brand:cheuklift
Model:JAMWP6000
MOQ:1 Sets
Send Inquiry
| Model | JAMWP18-6000 | JAMWP20-6000 | |
| Safe working load | kg | 160 | |
| Extending platform safe working load | kg | 120 | |
| (forbidden when lifting) | |||
| Maximum working height | mm | 18000 | 20000 |
| Max platform height | mm | 16000 | 18000 |
| Overall length | mm | 2300 | |
| Overall width | mm | 1300 | |
| Overall height | mm | 2500 | |
| Working platform size | mm | 1600×1080 | |
| Platform extending Length | mm | 750 | |
| Minimum ground clearance | mm | 100 | |
| Wheelbase | mm | 1790 | |
| Min turning radius inner/outer wheel | mm | 2.5/4.6 | |
| Driving motor | 24VDC/1.5KW | ||
| Lifting motor | four masts | 24VDC/3KW | |
| dual masts | 24VDC/1.5KW | ||
| Travel Speed | km/h | 4 | |
| Lifting/ descending speed | sec | 110/80 | 120/90 |
| Accumulator | 4×6V/250Ah | ||
| Lifting | four masts | 4×6V/250Ah | |
| dual masts | 2×12V/120Ah | ||
| Charger | 24V/15-30A | ||
| Gradeability | % | 15 | |
| Driving wheel | mm | Ф254×80 | |
| Front wheel | in | 10 | |
| Rear wheel | in | 6 | |
| Overall weight | kg | 2310 | 2380 |
