Brand:cheuklift
Model:GTWY1000
MOQ:1 Sets
Send Inquiry
| 1KG=2.2LB 1INCH=25.4MM | |||
| Model | GTWY1.3-1000 | GTWY1.6-1000 | |
| Safe working load | kg | 200 | |
| Maximum working height | mm | 3300 | 3600 |
| Maximum platform height | mm | 1300 | 1600 |
| Overall length | mm | 980 | |
| Overall width | mm | 600 | |
| Overall height | mm | 1790 | 1990 |
| Working platform size | mm | 600x600 | |
| Minimum ground clearance | mm | 40 | |
| Wheelbase | mm | 910 | |
| Lifting motor | kw | 12VDC/0.8KW | |
| Lifting/ descending speed | 11/9sec | 13/11sec | |
| Accumulator | 12v/95Ah | ||
| Charger | 12v/15A | ||
| Rear wheel | mm | 150x150 | |
| Front wheel | mm | 80x36 | |
| Overall weight | kg | 155 | 165 |
