Brand:QIANLI
Model:HS-VT
MOQ:2 Sets
HS-VT SERIES manual chain hoist
Eight characteristics make them hight ability and security,full of intelligence and skillful and greatly reduce work intesion.
| Model | HS-VT | HS-VT1 | HS-VT1.5 | HS-VT2 | HS-VT3 | HS-VT5 | HS-VT10 |
| capacity(Ton) | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 |
| standard lifting height(m) | 2.5 | 2.5 | 2.5 | 3 | 3 | 3 | 3.5 |
| test load(Ton) | 0.75 | 1.5 | 2.25 | 3 | 4.5 | 7.5 | 15 |
| min distance between hooks(mm) | 285 | 315 | 340 | 380 | 475 | 600 | 700 |
| chainpull to lift full load(N) | 25 | 33 | 34 | 34 | 35 | 39 | 41 |
| No.of load chain fall lines | 1 | 1 | 1 | 1 | 2 | 2 | 4 |
| diameter of load chain(mm) | 1.6 | 7.1 | 7.1 | 8 | 7.1 | 9 | 9 |
| net.weight(kg) | 8.4 | 11 | 13.5 | 21 | 22 | 40 | 77 |
| Gw.(kg) | 9.4 | 12 | 14.5 | 22 | 23 | 41.5 | 85 |
| packing dimention(L*W*H)cm | 30×17 | 30×17 | 30×17 | 28×19 | 30×17 | 40×20 |
