200m Q345B Steel Topkit Tower Crane For Large Goods Yard / Bridges

1. Specification: TC7013-12

2. Dimensions: standard section 2,000mmX2,000mmX3,000mm

3. Material: All main chord is in Q345B steel

4. Parameter: Maximum hoisting capacity 10 tons,the longest jib is 70m, maximum independent lifting height 60m, maximum attached height 200m

5. Model number: QTZ160

6. Application: Suitable for construction of medium and high-rise commercial, civil buildings and such large projects as roads and bridges, power stations, etc. as well as construction of large goods yard, wharf, etc.

Quick Detail:

TC7013-12 tower crane (QTZ160)

1. Flat top tower crane with convenient installation and disassembly, is very suitable for cross tower crane group.

2. The mast used monolithic standard section of 2,000mmX2,000mmX3,000mm.

3. The longest jib is 70m, the arm length combination reduces for every 5m and the minimum jib length is 45m.

4. The maximum hoisting capacity is 10 tons.

5. The maximum lifting capacity at a distance of 70m is 1.3 ton.

6. The maximum hoisting moment is 185t.m.

7. The maximum independent height is 60m and the maximum attached height is 200m.

8. Hoisting mechanism: Adopting a variable frequency motor   30KW for power. Slew mechanism: Adopting a torque motor   3.7 KWX2 for power.  Luffing mechanism: Adopting a variable frequency motor    3.3KW for power

9. Tower crane foundation type: Leg fixing type

Description:

1. The mast used monolithic standard section of 2,000mmX2,000mmX3,000mm.

2. The longest jib is 70m, the jib length combination reduces for every 5m and the minimum jib length is 45m.

3. The maximum hoisting capacity is 10tons.

4. The maximum lifting capacity at a distance of 70m is 1.3 ton

5. The maxim
