Introduction：

Activated carbon filter element is a new type deep layer filtrating product . It using active carbon particles to low hot melt sexual binder , continuous extrusion sintering forming . The innermost of filter element is PP skeleton use it to strengthen compression strength of filter element . There are two layer PP fiber felt on the skeleton , can stop the more than 10 microns particles which brought out by the liquid through carbon core . Outer sphere of carbon core have two layer PP superfine fiber felt , can stop the more than 10-20 microns particles which in liquid , so the filter element have double function – filtrating and cleansing . It can effective move organic matter in liquid , particulate , rust , residual chlorine , peculiar smell . etc .

Scope of application

Activated carbon filter element are widely used in pure want , electroplating line , printed circuit board , coating , solvents , detergent , medicine water , oral liquid , pharmaceutical injection , beverage , wine industries liquid filtration , compressed air filtrating , air filtrating .

Mine feature :

1.      set adsorption , filtration , intercept , catalysis in one body .

2.      acid , alkali , salt and different kinds of organic solvent .

3.      high filtrating precision , big flow , small differential pressure , high compression strength , big quantity accept dirt . non-toxic , tasteless , non secondary pollution .

Performance index

1.      Iodine adsorption value : 900 mg/g

2.      Benzene adsorption value : 20-25 %

3.      Methylene blue adsorption values : 13-16 ml/g

4.      Removal rate of COD : 58.25 %

5.      Residual chlorine removal rate : more than 96.83 %

Technical parameters :
