Technical data:
1) Size and output of major products:
A) Hollow blocks: 400x 200 x 200mm, 7.5PCS/mould
B) Perforated bricks: 240 x 115 x 90mm, 20PCS/mould
C) Interlocking ripples: 20PCS/mould
D) Solid bricks: 240 x 115 x 53mm, 40PCS/mould
E) Curbing: 1000 x 300 x 120mm, 2PCS/mould
2) Pallet size: 1100 x 680mm
3) Cycle time: 12 - 25 seconds
4) Type of major vibration: Table vibration
5) Vibration frequency: 2800 - 4500 times/minute
6) Total power: 42.9kW
7) Rating pressure: 21Mpa
8) Profile size (including pallet delivering device and green block delivering device): 6800 x 2090 x 3000mm
9) Weight: 19840kg
