Brand:SIMUWU
Model:RVSG-559
MOQ:1 Sets
Send Inquiry
SILICON CARBIDE VACUUM SINTERING FURNACE
It is used in New materials reaction sintered silicon carbide. The maximum temperature is 1800℃. With glue, dust removal system, complete evacuation and sintering meanwhile, It has horizontal and vertical two types.
Tel: 86-21-50878190
E-mail: simuwu@vacfurnace.com
Skype: Kevin.law012
Web site: www.vacfurnace.com
Specifications:
| Main technical data of Silicon carbide sintering furnace | |||||
| Model | Effective working Dimension (mm) | Max temperature (℃) | Ultimate pressure (pa) | Pressure rising rate(pa/h) | Temperature Uniformity(℃) |
| RVSG-446 | 400×400×600 | 1800 | 6×10-1 | 0.5 | ±5 |
| RVSG-559 | 500×500×900 | 1800 | 2×10-1 | 0.5 | ±5 |
| RVSG-4413 | 400×400×1300 | 1800 | 2×10-1 | 0.5 | ±5 |
| RVSG-8810 | 800×800×1000 | 1800 | 2×10-1 | 0.5 | ±5 |
| RVSG-8832 | 800×800×3200 | 1800 | 2×10-1 | 0.5 | ±5 |
| Vertical RVSG-4555 | Φ450×550 | 1800 | 2×10-1 | 0.5 | ±5 |
| Vertical RVSG-5070 | Φ500×700 | 1800 | 2×10-1 | 0.5 | ±5 |
