Brand:jieda ultrasonic
Model:JD-1200
MOQ:1 Sets
Inner earloop mask welding machine JD-1200
Introduction:
This machine weld the earloop elastic at the both inner side of mask, it is a semi-automatic machine that finished the whole mask.
Machine features:
| 1. High stability, excellent performance. |
| 2. Made in the main machine by the materials of qualities aluminum alloy, strong and stainless. |
| 3.Panel adopt hardening treatment |
| 4.Adjustable ultrasonic welder |
| 5. PLC microcomputer control. |
Specification:
| Machine Dimensions | 1970(L)*1000(W)* 1900(H)mm |
| Transport machine | 1510(L)*410(W)*750(H)mm |
| Driving way | Servo motor |
| Electric Control | PLC |
| Voltage | 220V, 50/60HZ, |
| Power consumption | 5.5KW |
| Compressed air | 1HP |
| Speed of Manufacture | 40-50 PCS /Min |
| Mask Size | Standard:175*95mm |
| Gross weight | 520KG |
