ITEMS         SPECIFICATION
Control  method         PC+IPC+PLC
Convey or motor         1P  AC220V,60W
Convey or speed         0-1800mm/min
PCB  size         30-350mm(w)
Fluxcapacity         6L
Pre-heating zone         1800mm,room temperature--250 C
Solder pot temperature         1KW*10PCS room temperature---300 C
Solder pot capacity         350KG
Wave motor         3P  AC220V,0.18KW*2PCS
Finger cleaning pump         1P  AC220V 6W
Convey or direction         L-R (R-Loptional)
Convey or  angle         3_6
Flux  pressure         3_5BAR
Power supply         AC380V 50HZ
Normalworkingpower/         8KW/25KW
Outside dimension         4300(L)*1400(W)*1700(H)
Dimension         3400(L)*1400(W)*1700(H)
Net weight         1200KG
