Brand:-
Model:-
MOQ:1 Sets
Features and Advantages
1. Comparing with conventional cutting machine, high arcing success rate, concentrated energy, strong cutting capacity, high cutting speed, narrow cutting gap , smooth cutting surface, small distortion, etc;
2. comparing with flare cutting machine, by using cheap compressed air as cutting gas source:
3. Compact in volume, lighte in weight, easy to carry, especially suitable for outdoor movable operation;
4. Optimized design layout, high frequency inverter, high duty cycle, low energy consumption;
5. metal plates with different thicknesses can be curve cut into any shape;
6. Over heat, over current, over voltage, etc protective electric circuit built-in, safety operation.
| Power Voltage (V): | AC380±15% | Power Frequency: | 50/60HZ |
| No-load Loss(W): | 40 | Duty Cycle (%): | 60 |
| Efficiency (%): | 85 | Power Factor: | 0.93 |
| Output Current (A): | 20-60 | No-load Voltage(V): | 240 |
| Rated Output Volt.(V): | 104 | Rated Input Current (A): | 10.4 |
| Rated Output Current (A): | 40 | air Pressure comprssor : | 4-5(KG) |
| Arc-starting: | HF/touch | Insulation Grade: | F |
| Housing Protection Grade: | IP21 | Max Thickness(mm): | 20 |
| Dimensions(mm): | 480*204*303 | Weight (kg): | 19 |
Accessory
1) One pcs SG-55 high quality cutting torch with 8 mm2 cable and thicker cover to pretect the torch.
2) One pcs earth clamp with lead.
3) One pcs air pressure regulator.
4) One pcs air hose.
5) Two pcs hose clamps.
6) One set free consumables for SG-55.
