Product Description:

A: Material: air spring, cold-rolled steel Q235 etc

B: Finish: powder-coated, plated (brass + nickel + sealing)

Feature:

A: Easy to operate and save the space, opening and closing silently.

B: wide range of options for users.

C: Application for a variety of different specifications , material and weight upward opening door, easy to install.

D: Easy to install, 3-D adjustment is achieved for the door.

E: Suitable for light-duty door.

F: Compare with YS337-A kitchen door lofting mechanism, with different polish and connecting bar.

Product Advantage:

A、The door itself lift up slowly after pulling for 10cm,

B、Closing silently without any noise and shock.

Product Parameter:

A: Application: For microwave oven used kitchen cabinet and office file cabinet

B: Installation: Pls refer to the chart below.

C: Door Height : 600mm - 900mm can be achieved

• 600mm height of cabinet: using with 541mm connecting rod.
• 900mm height of cabinet: using with 826mm connecting rod.
• maximum front projection: 193mm

D: Cycles: 50,000times

Others (packing and service)

A: Package: 1 set/inner box, 6 inner boxes/carton

B: N.W. : 11.5/13kgs

C: MEAS: 80.5*45*13cm

D: Delivery Date: Normally in one month.

E: MOQ: 500sets

F: Payment term: T/T
