Pillow & cushion automatic weighing & filling line BC106
| Model BC106 | Fiber carding machine BC1001-1000 | Fan feeding machine BC503 | Weighing system BC1028 （2PCS） | Filling machine BC502-2 |
| Dimensions （mm） （L*W*H） | 2150*1130*940 | 610*520*800 | 3300*1420*3800 （2PCS） | 1150*1100*1000 1000*900*1290 |
| Power | 6.25KW | 2.2KW | 5KW | 2.3KW |
| Net weight | 800Kg | 75Kg | 2500Kg | 300Kg |
| Capacity | 200-250 Kg/hour （5-6）pcs/min | |||
| Voltage | 380V，50Hz，3Phase | |||
△ The system can realize fiber carding, accurate weighing and high speed filling.
△ High technology: Having the most advanced weighing system, the operator can set the fiber weight with touch screen panel, fully automatic and accurate. The handling weight: 150g-1500g.
△ More safety: The fiber carding machine has metal detector and overloading alarm system to avoid the machine being damaged.
△ Cost-saving: Place an additional bale opening machine, it only needs one person to run the whole line.
△ Two heads filling machine with patting devices ensure the high speed and top-quality filling.
△ Since the line adpots two pcs automatic weighing system, comparing with the line with one automatic weighing system ,it is very fast and efficient.
