Features and Benefits:
● Powered by Wangye 4-Stroke air-cooled Diesel Engine.
● Compact and portable power for emergency and home standby use.
● Circuit breaker protects overload operation.
● Emergency low oil alert warn the low lube oil level.
● Large muffler for quiet operation.
● AVR alternator provides stable voltage and current.
● Standard configuration of voltmeter.
A.T.S. control box with digital display:
(1) While the Mains Supply is failure, the ATS will start the generator automatically
within 3-28 seconds (time can be adjustable).
(2) If the commercial power (home power/city power) recovers, the ATS will transfer to
the commercial power supply automatically and stop the generator after 23-230 minutes
to protecting the damage of the engine parts by sudden stopping.
(3) Included four protection device: alarm and shutdown to low oil pressure,
high coolant temperature, over-speed and emergency stop.
about:
Rated output 4.2kW,Max. output 5.0kW,single Phase,AVR
9HP,Diesel,Single Cylinder,4-Stroke,Electric Start.
Description:
| Model | WDG5000S/WDG5000S(ATS) | |
| Type | Revolving field type 2 poles generator | |
| Voltage Regulate | AVR | |
| AC Frequency (Hz) | 60 | 50 |
| AC Output Voltage (V) | 110;120;110/220;120/240 | 220;230;115/230 |
| Cont. AC Output (VA) | 4600 | 4200 |
| Max. AC Output (VA) | 5000 | 4600 |
| DC Output (V/A) | 12 / 8.3 | |
| Engine Model | WE186F | |
| Type | Single cylinder,Air-cooled,4-stroke vertical | |
| Starting System | Electric Start | |
| Fuel/Lub Capacity (L/in.) | 15(3.96) / 1.5(0.4) | |
| Fuel/Lub.oil | 0# in summer,-10# or -20# in winter/SAE10W30 | |
| Operating Noise Level (at 7m) | 67dB(A) | |
| Packing Dimensions (mm/in.) | 918x565x734 / 36.1x22.2x28.9 | |
