3-12mm Slitting Line heavy duty type with high precision and high quality

We produce series of Slitting Line for CR, HR, galvanized coil.
We offer high quality machine with competitive price

Components
It mainly includes coil car, uncoiler, shearer,  adjusting device, slitting machine, scrap recoiler, tension unit, press unit, recoiler and coil car, hydraulic system, ect.

Technical Parameters

1. slitting material:hot rolled coil, cold rolled coil, stainless steel

2. thickness: 3 - 12mm;

3. width: 600-2000mm;

4. slitted tolerance(width): ±0.10mm;

5. speed: 0 - 40m/min;

6. de-coiler capacity: max. 35T;

7. coil inner diameter : Φ500mm-Φ800mm

8. coil out diameter: ≤Φ2100mm;

9. re-coiler diamter: Φ760mm;

10. electrical resource: 380V, 3 phase, 50Hz; or up to the customers requirements.

11. PLC control system, touch screen, etc.
