Safety 120 / 2800 hp / rpm Max Power Coaster Mini Bus With Double Action Shock Absorbers
| Specifications | |||
| Model | HY6750 | ||
| DIMENSIONS & WEIGHTS | |||
| Overall dimension (mm) | Length | 7400 | |
|
| Width | 2040 | |
|
| Height | 2750 | |
| Wheelbase (mm) | 3800 | ||
| Thread (mm) | Front/rear | 1665/1525 | |
| Ground clearance (mm) | 215 | ||
| Seating capacity (persons) | 26+6 | ||
| ENGINE | |||
| Model | CY4102BZLQ (EURO II) Isuzu technology | ||
| Type | 4-cylinder, in line, water-cooled, direct injection, diesel, turbocharged | ||
|
| Inter-cooling | ||
| Bore & stroke (mm) | 102x118 | ||
| Displacement (cc) | 3856 | ||
| Max. Power (hp/rpm) | 120/2800 | ||
| Max. Torque (N-m/rpm) | 343/1600 | ||
| Fuel tank (liter) | 90 | ||
| DRIVE TRAIN | |||
| Clutch | Hydraulic, Single plate, dry type diaphragm spring | ||
| Gearbox | 5 speed manual | ||
| Max. gradeability (%) | 30 | ||
| CHASSIS | |||
| frame | Ladder shaped, ‘] ’ section | ||
| Suspensi Contact Infomation
