Brand:EVP
Model:CCQA
MOQ:1000 Pieces
CCQA pneumatic ultra-high vacuum gate valve
Description: CCQ-A pneumatic ultra-high vacuum gate valve takes the compressed air as power, change the direction of air passage by solenoid directional valve
Product info
CCQ-A pneumatic ultra-high vacuum gate valve takes the compressed air as power, change the direction of air passage by solenoid directional valve, and controls the actuating cylinder to drive the valve plate up and down to make the valve opened or closed. Thus reaches the aim of put through or cut off the air passage in vacuum pipeline. Applicable medium can be pure air and noncorrosive gases.
Specifications
Main Technical Performance
| Applicability (Pa) | 105～1.3x10-7 |
| Valve Leak Rate(Pa.L/S) | DN≤200为≤1.3x10-7 |
| Applicable Temperature （℃） | ≤150(except gearing) |
| The differential pressure between the two sides of valve plate upon valve opening(Pa) | ≤2.7x103 |
| air pressure （MPa） | 0.4～0.6 |
| Power supply voltage | standard：AC220V/50Hz |
| signal feedback | Standard：without signal feedback |
