Plain gauge glass / transparent sight glass

It’s made from borosilicate glass. it is used in lever gauge in boiler for water position. It is also named transparent gauge glass, sight glass, borosilicate transparent glasses, transparent sight glass, plain gauge glass.

Sight glass/gauge glass (transparent plane)
340 x 34 x 17mm, 320 x 34 x 17mm, 280 x 34 x 17mm
250 x 34 x 17mm, 218 x 34 x 17mm, 216 x 34 x 17mm
190 x 34 x 17mm, 165 x 34 x 17mm, 215 x 34 x 22mm
218 x 38 x 23mm, 190 x 38 x 23mm, 165 x 38 x 23mm
The other size is optional or according to the requirements of customers.
Working temperature: 260 degree C, Working pressure: 6.3 MPa

Packing: each piece in a box and then in carton.
