Brand:SYMH
Model:6816
MOQ:500 Pieces
Send Inquiry
6816 Bearing type:Deep Groove Ball Bearing, Dimensions: 80 x 100 x 10 mm, Capped variants: 6816ZZ, 6816VV, 6816DD.
SYMH 6816 Deep Groove Ball Bearings specification:
| New Model: | 6816 |
| Inside diameter (ID d): | 80 mm |
| Outside diameter (OD D): | 100 mm |
| Thickness (B/T/H): | 10 mm |
| Basic dynamic load rating (Cr): | 12.7 kN |
| Basic static load rating (Cor): | 13.3 kN |
| Reference speed (Grease rpm): | 6000 r/min |
| Limiting speed (Oil rpm): | 7000 r/min |
| Weight, Mass (M): | 0.155 kg |
| Brand: | SYMH |
| Bearing type: | Deep Groove Ball Bearings |
