NGP-SC70 Reinforced Non asbestos Composite Cylinder Head Gasket Sheet
Description
Manufactured from non-asbestos beater sheet with tanged (perforated) of 0.18mm ~ 0.25mm tinplate inserted reinforcement. It is best material for cylinder head gasket, exhaust gasket and other engine gasket seal.

Composite Type:
SC70-A Non-asbestos + Steel + Non-asbestos
SC70-B Non-asbestos + Steel + Non-asbestos + Steel + Non-asbestos
SC70-C Steel + Non-asbestos
SC70-D Steel + Non-asbestos + Steel
SC70-E Both Size Graphite Coating Reinforced Non-asbestos Composite Sheet

Product Data Sheet:
Density: 1.40g/cm3 Min
Compressibility: 8%--12%
Recovery: 50% Min
ASTM F146 3# OIL 150 C × 5h
Thickness increase: 15% Max
Weight increase: 10% Max
ASTM F146 Fuel B R.T × 5h
Thickness increase: 10% Max
Weight increase: 10% Max

Standard Sheet Size:
500mm x 1000mm
500mm x 1200mm
500mm x 1500mm
510mm x 1016mm
510mm x 1530mm
1000mm x 1000mm
1000mm x 1500mm
Thickness: 1.0mm ~ 2.5mm
The other size and thickness are optional or according to the requirements of customers
