Unique Human Voice Alarm system

The device triggered the human voice prompt and stop injection automatically when there is any malfunction, making the infusion process safer and more reliable.

Injection Rate:

50/60ml Syringe:  0.1ml/h~999.9ml/h   (0.1ml/h step)
1,000ml/h~1,500ml/h   (1ml/h  step)
30ml Syringe: 0.1ml/h~900.0ml/h    (0.1ml/h step)
20ml Syringe:  0.1ml/h~600.0ml/h   (0.1ml/h step)
10ml Syringe:  0.1ml/h~300.0ml/h   (0.1ml/h step)

Flow Rate Accuracy:

Within �3% (after correct calibration)

Mechanical precision:

Within �2%

Bolus Rate:

50/60ml Syringe:  1,200ml/h
30 ml Syringe:  720ml/h
20 ml Syringe:  480ml/h
10 ml Syringe:  240ml/h

Purge Rate:

50/60ml Syringe:  1,500ml/h
30ml Syringe:  900ml/h
20ml Syringe:  600ml/h
10ml Syringe:  300ml/h

Volume Limit:

0.1ml~999.9ml

Total Injection
Volume:

0.1ml~9999.9ml (0.1ml step)

Occlusion:

High:   800mmHg �200mmHg     (106.7kPa�26.7kPa)
Medium: 50/600mmHg �100mmHg  (66.7kPa�13.3kPa)
Low:    300mmHg �100mmHg    (40.7kPa�13.3kPa )

Alarms:

Injection soon finish, end of injection,occlusion, improperly installation of syringe, wrong setting, low battery, syringe loose etc.

Power Source:

AC 100V~240V, 50/60Hz; Internal rechargeable Li battery, capacity=1,600mAh, 4 hours internal battery backup

KVO rate:

1ml/h

Fuse:

F1AL/250/60V, 2pcs inside

Power Consumption:

30VA

IP Classification:

IPX4

Equipment Classification:

Class I, internal power supply, Type CF

Operating Condition:

Ambient temperature: +5?~+40?;

Relative humidity:

20~90%

Transport & Storage Condition:

Ambient temperature: -30?~+55?

Relative humidity:

=95%

Dimension:

280mm (L) � 210mm (W) � 130mm (H)

Weight:

2.2kg (net weight)
