Features

●Portable and delicate design, easy to operate

●Accurate pulse pace identification function

●High accuracy digital filter, automatic baseline adjustment

●Working modes: Manual, Automatic, Arrythmia Analysis, Storage

●80mm, 3 channel format recording, excellent automatic interpretation

●320x240 graphic 3.5 inch color LCD to simultaneously display ECG information

●250 patient cases storage ( SD card storage is optional )

●Detailed patient information record

●Freeze function

●Adapt to 110-230V,50/60Hz power supply. Built-in rechargeable Ni-MH battery continuously working for about 3 to 4 hours.

●USB / Rs232 communication ports support USB storage, laser printer printing and PC ECG software ( Optional )

Technical Specifications

● Leads: standard 12 leads

● Patient current leakage: ＜10μA

● Lead acquisition:12bit/1000Hz（synchronously 12 leads ）

● Calibrating voltage: 1mV±2％

● Work mode: Manual, Auto, R-R analysis

● Voltage tolerance: ≥±500mV

● Time constant: ≥3.2s

● Frequency response: 0.05～160Hz(-3db)

● Input dynamic range:±10Vpp

● Sensitivity valve: ≤20μV

● Sensitivity: Auto,2.5, 5, 10, 20,40mm/mV（±3％）

● Inter-channel Interference: ≤0.5mm

● Paper speed: 6.25,12.5, 25, 50mm/s（±
