Specifications

■ Display: 3.5" TFT
■ Display mode: Parameter mode & Waveform face
■ Battery:
     Builtin Li-Polymer, 6 hours for charging , 3.7v,1900mah
     9 hours for continous working in the mode 1 or 2
     3 hours for continou working in the mode 3 or 4
     4 hours for continous working in the mode 5
■ Trend Graph/Table:
    Resolution from 1s, 5s, 10s,30s,1min,and so on. Storage of latest 96 hours
    trend data.
■ SpO2 drop analysis
■ History:
    Storage of latest 10000 case history in SD card.
■ Wave:
    Storage of 24 hours waveform, and only the real time stored patients have
    waveform
■ Alarm:
    Ajustable High and Low limits . Three level audible and visual alarm , latest
    50 alarm information and waveform displays 8 sec-onds which 4 seconds
    are before a certain time when the alarm is turned on and 4 seconds are
    after appointed time  when the alarm is turned on.

SPO2

■ Measurement Range: 0 ~ 100%
■ Resolution: 1%
■ Accuracy: ± 2 % (70% ~ 100% )
                         0% ~ 69% unspecified
■ Alarm Range: 0% ~ 100%
■ Refreshing Rate: 1s

Pulse Rate:

■ Measurement Range: 25 ~ 250 bpm
■ Alarm Range: 25 ~ 250 bmp
■ Resolution: 1bpm
■ Accuracy: ± 3 bpm
■ Refreshing Rate: 1s

ETCO2:

■ Measurement Range: 0 ~ 150 mmHg
■ Resolution: 0.1mmHg
■ Accuracy: ± 2mmHg
■ Alarm Range: 0 ~ 150 mmHg

AWRR:

■ Measurement Range: 0 ~ 150 bpm
■ Resolution: 1bpm
■ Accuracy: ± 1bpm
■ Alarm Range: 0~ 150bpm

Components

■ Main Unit
■ SpO2 Sensor
■ 1 G HIghSpeed SD Card
■ MicroStream EndTidal CO2 Module
