Major Features
◆Small in volume、light in weight and convenient in carrying
◆Operation of the product is simple ,low power consumption
◆Operation menu for the function setting
◆SpO2 value display
◆Pulse rate value display, bar graph display
◆Pulse waveform display
◆Screen brightness can be changed
◆A pulse rate sound indication
◆Review function
◆With measured data overruns limits and low-voltage alarm function,  the upper/down alarm range is adjustable
◆Battery capacity indication)
◆Low-voltage indication: low-voltage indicator appears before working abnormally which is due to low-voltage ,and with alarm function
◆With SpO2 value and pulse rate value of storage, the storage data can be uploaded to computers
◆Real-time data can be transmitted to computers
◆Connected with an external oximeter probe
◆Wireless communication function(CMS60DW)
Main performance
Display Mode: 1.8" Color OLED display
Screen Resolution: 160*128
SpO2 Measuring Range: 0%～100%, (the resolution is 1%).
Accuracy: 70%～100%: ±2% ,Below 70% unspecified.
PR Measuring Range: 30bpm～250bpm, (the resolution is 1bpm)
Accuracy: ±2bpm or ±2% (select larger)
Measurement Performance in Weak Filling Condition:
SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger).
Resistance to Surrounding Light: The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.
Power Consumption: less than 100mA
Voltage: DC 3.0V
Power Supply: Alkaline battery(2AA)
Battery Working Hour: Theoretical number is 44 hours.
Safety Type: Interior Battery,  BF Type
Accessories
Sell in standard:
◆A user manual
◆A data line
◆A disk (PC software)
◆An oximeter probe
Sell in addition:
◆Other oximeter probe(Refer to probe application instruction for details and notice renewal）

Physical Identity
Dimension: 110(L) × 60(W) × 23(H) mm
Weight: about 180g (with Alkaline  battery(2AA))

Qualification
CMS60D passed FDA and CE
