Detecting method:Magnetic induction

Detecting width:400mm

Detecting height:100-300mm

Detecting adjustment:Stepless adjustment

Detection sensititivity 0.8-2.5mm, more than  2.5mm(colored and black metal)

Alarm method:Buzzer&LEDs indicator twinkles and shutdown  automatically

Belt speed:(appr.)40m/min

Power supply:AC380V,50-60Hz

Weight:130-150kg

Dimension size:1620(L)?000(W)?100(H)MM

1. Uses a two-way signal detection circuit technology combined with high sensitivity and high anti-interference ability.

2. With two-way signal display. When the metal has passed, the signal level indicator based on the size of the metal show different induction Intensity.

3. Signal processing by the digital circuit to complete, easy adjustment, stable and reliable.

4. Product effect with regulatory function, such as moist products, sugary products, salt of the food, will have a type of metal detector metal may signal that this effect will affect the detection results, which function to reduce the effect of Product to Detect a better effect.

5. Frederick has a leak-proof function. When there are multiple signals through the metal, the apparatus will automatically detect the signal frequency, the executing agency in the action will not Have missed.

6. Detect when there is no object when it was passed, apparatus in a sleep state, only the object through the detection to be valid.

7. Production line can be used to connect supporting the implementation of automatic detection pipeline.

8. Monitor the use of sound and light alarm, automatically exclude or shutdown, the operational use of extremely reliable and user-friendly.

9. Can be used all-stainless steel materials.
